Home  >  Motors  >  HVAC  >  Direct Drive  > 5KCP39PGE414T MOTOR

5KCP39PGE414T MOTOR

No. of Poles 4 Motor Type PSC Enclosure OAO HP (Max.) 3/4 Voltage 208-230 Mounting 8 Shell Mtg Holes Speeds 3 Hz 60 Rotation CW/CCW RPM Range 1075 NEMA Frame Size 48 Phase Single Standards UR/CSA FLA 4.5 Bearing Ball Lead Length (in.) 30 Thermal Protection Yes Ambient Deg C 40 Ins. Class B Shaft Dia. (in.) 1/2 Capacitor Included No Shaft Length (in.) 6.5 Capacitor Rating 10/370 Service Factor 1.0 Duty Continuous
Item #: 03990
5KCP39PGE414T MOTOR

Direct Drive Fan & Blower Motor

  • Permanent Split Capacitor (PSC), Capacitor required
  • 38" Leads
  • 1/2" Diameter Shaft with Double Flat
  • Resilient Ring Mounting, Extended Clampbolts

Motors

No. of Poles
4
Motor Type
PSC
Enclosure
OAO
HP (Max.)
3/4
Voltage
208-230
Mounting
8 Shell Mtg Holes
Speeds
3
Hz
60
Rotation
CW/CCW
RPM Range
1075
NEMA Frame Size
48
Phase
Single
Standards
UR/CSA
FLA
4.5
Bearing
Ball
Lead Length (in.)
30
Thermal Protection
Yes
Ambient Deg C
40
Ins. Class
B
Shaft Dia. (in.)
1/2
Capacitor Included
No
Shaft Length (in.)
6.5
Capacitor Rating
10/370
Service Factor
1.0
Duty
Continuous
