Home  >  Motors  >  HVAC  >  Condenser Fan  > 1/3 HP 208-230V 825 B/B CF MTR

1/3 HP 208-230V 825 B/B CF MTR

No. of Poles 8 Motor Type PSC Enclosure TEAO HP (Max.) 1/3 Voltage 208-230 Mounting Thru Bolt/Belly Band Speeds 1 Hz 60 Rotation REV RPM Range 825 NEMA Frame Size 48 Phase Single Standards UR/CSA FLA 1.9 Bearing Ball Lead Length (in.) 36 Thermal Protection Yes Ambient Deg C 60 NOTE Horizontal or Vertical Ins. Class B Shaft Dia. (in.) 1/2 Capacitor Included No Shaft Length (in.) 6.5 Capacitor Rating 7.5/370 Service Factor 1.0 Duty Continuous
Item #: 10205
1/3 HP 208-230V 825

MARS Outdoor Condenser Fan

  • Vertical Shaft Up or Shaft Down
  • Weep hole in each end shield
  • Rheem mounting holes w/screws installed
  • Water slinger on shaft
  • Double full flatted shaft
  • Thermally Protected
  • Extended Studs/Belly Band/Mounting Holes
  • Motors

    No. of Poles
    8
    Motor Type
    PSC
    Enclosure
    TEAO
    HP (Max.)
    1/3
    Voltage
    208-230
    Mounting
    Thru Bolt/Belly Band
    Speeds
    1
    Hz
    60
    Rotation
    REV
    RPM Range
    825
    NEMA Frame Size
    48
    Phase
    Single
    Standards
    UR/CSA
    FLA
    1.9
    Bearing
    Ball
    Lead Length (in.)
    36
    Thermal Protection
    Yes
    Ambient Deg C
    60
    NOTE
    Horizontal or Vertical
    Ins. Class
    B
    Shaft Dia. (in.)
    1/2
    Capacitor Included
    No
    Shaft Length (in.)
    6.5
    Capacitor Rating
    7.5/370
    Service Factor
    1.0
    Duty
    Continuous
    MFG NameMFG #
    Century/AO SmithFE1038SF, FSE1038SF
    US Motors/Emerson1875
    GE/Genteq3205
    MarathonX451
    Packard30825
    ROTOMCF-813
    York/Source 1S1-FHM3205

    Be careful! The information provided is intended to serve as a reference to assist in the selection of products sold by MARS. It is the responsibility of users to validate any cross reference information provided to determine suitability for the intended application. The company is using the competitor's brand names for reference only, and without license or permissions of those companies.
