Home  >  Motors  >  HVAC  >  Direct Drive  > HI EFFICIENCY DIRECT DRIVE

HI EFFICIENCY DIRECT DRIVE

1/2HP 208-230V 1075 RPM MOTOR
No. of Poles 6 Motor Type PSC Enclosure OPAO HP (Max.) 1/2 Voltage 208-230 Mounting ThruBolt/All Angle Speeds 3 Hz 60 Rotation REV RPM Range 1075 NEMA Frame Size 48 Phase Single Standards cULus FLA 2.5 Bearing Ball Lead Length (in.) 36 Thermal Protection Auto Ambient Deg C 40 Ins. Class B Shaft Dia. (in.) 1/2 Capacitor Included No Shaft Length (in.) 4.5 Capacitor Rating 10/370 Service Factor 1.0 Duty Continuous
Item #: 10578

MARS Hi Efficiency Direct Drive Motors

  • Permanently lubricated ball bearings
  • Rheem mounting holes
  • Extended thru bolts shaft end
  • 3 Speed, Single Phase
  • Capacitor required: 10 MFD 370V
  • (2)2-1/4 & (2)2-1/2 Resilient Rings
  • Thermal protected, air over
  • 36 in. Leads
  • Motors

    No. of Poles
    6
    Motor Type
    PSC
    Enclosure
    OPAO
    HP (Max.)
    1/2
    Voltage
    208-230
    Mounting
    ThruBolt/All Angle
    Speeds
    3
    Hz
    60
    Rotation
    REV
    RPM Range
    1075
    NEMA Frame Size
    48
    Phase
    Single
    Standards
    cULus
    FLA
    2.5
    Bearing
    Ball
    Lead Length (in.)
    36
    Thermal Protection
    Auto
    Ambient Deg C
    40
    Ins. Class
    B
    Shaft Dia. (in.)
    1/2
    Capacitor Included
    No
    Shaft Length (in.)
    4.5
    Capacitor Rating
    10/370
    Service Factor
    1.0
    Duty
    Continuous
    MFG NameMFG #
    Century/AO SmithD1056, FD1056, F1076SV1
    US Motors/Emerson5461, 1973
    FascoD703
    GE/Genteq3988, 3588
    Magnetek0528
    MarthonX005
    Packard43588, 63988

    Be careful! The information provided is intended to serve as a reference to assist in the selection of products sold by MARS. It is the responsibility of users to validate any cross reference information provided to determine suitability for the intended application. The company is using the competitor's brand names for reference only, and without license or permissions of those companies.
