Home  >  JARD  >  JARD Motors  >  JARD Condenser Fan  > 1/5HP 208-230V 1075RPM 70C CF

1/5HP 208-230V 1075RPM 70C CF

No. of Poles 6 Motor Type PSC Enclosure Drip Proof HP (Max.) 1/5 Voltage 208-230 Mounting Belly Band, Extended Clampbolts Speeds 1 Hz 60 Rotation REV RPM Range 1075 NEMA Frame Size 48 Phase Single Standards CUL FLA 0.9 Bearing Ball Lead Length (in.) 48 Thermal Protection Auto Ambient Deg C 70 Ins. Class B Shaft Dia. (in.) 1/2 Capacitor Included No Shaft Length (in.) 6.5 Capacitor Rating 5/370 Service Factor 1.0 Duty Continuous
Item #: 26726
1/5HP 208-230V 1075

JARD 70C Condenser Fan Motor

  • Ball Bearing, Reversible
  • Vertical Shaft Up or Shaft Down
  • Weep hole in each end shield
  • Rheem mounting holes w/screws installed
  • Water slinger on shaft
  • Double full flatted shaft
  • Thermally Protected
  • Extended Studs/Belly Band/Mounting Holes
  • Motors

    No. of Poles
    6
    Motor Type
    PSC
    Enclosure
    Drip Proof
    HP (Max.)
    1/5
    Voltage
    208-230
    Mounting
    Belly Band, Extended Clampbolts
    Speeds
    1
    Hz
    60
    Rotation
    REV
    RPM Range
    1075
    NEMA Frame Size
    48
    Phase
    Single
    Standards
    CUL
    FLA
    0.9
    Bearing
    Ball
    Lead Length (in.)
    48
    Thermal Protection
    Auto
    Ambient Deg C
    70
    Ins. Class
    B
    Shaft Dia. (in.)
    1/2
    Capacitor Included
    No
    Shaft Length (in.)
    6.5
    Capacitor Rating
    5/370
    Service Factor
    1.0
    Duty
    Continuous
