Home  >  Motors  >  HVAC  >  Oil Burner  > 1/7HP 115V 3450 RPM

1/7HP 115V 3450 RPM

OIL BURNER MOTOR
No. of Poles 2 Motor Type PSC Enclosure Semi Enclosed HP (Max.) 1/7 Voltage 115 Mounting Two bolt direct mounting Speeds 1 Hz 60 Rotation REV RPM Range 3450 Phase Single Standards cULus FLA 1.5 Bearing Ball Lead Length (in.) 14 Thermal Protection Auto Ambient Deg C 40 Ins. Class B Shaft Dia. (in.) 1/2 Capacitor Included No Shaft Length (in.) 1.75 Service Factor 1.0 Duty Continuous
Item #: 30701

MARS PSC Oil Burner Motor

  • Residential/Commercial
  • For Oil Burner, Hot Water, Pressure/Steam and more
  • Two bolt direct mounting
  • Single Phase
  • Semi-Enclosed
  • Automatic Reset Overload
  • Motors

    No. of Poles
    2
    Motor Type
    PSC
    Enclosure
    Semi Enclosed
    HP (Max.)
    1/7
    Voltage
    115
    Mounting
    Two bolt direct mounting
    Speeds
    1
    Hz
    60
    Rotation
    REV
    RPM Range
    3450
    Phase
    Single
    Standards
    cULus
    FLA
    1.5
    Bearing
    Ball
    Lead Length (in.)
    14
    Thermal Protection
    Auto
    Ambient Deg C
    40
    Ins. Class
    B
    Shaft Dia. (in.)
    1/2
    Capacitor Included
    No
    Shaft Length (in.)
    1.75
    Service Factor
    1.0
    Duty
    Continuous
    MFG NameMFG #
    US Motors/Emerson3247
    MarathonO701

    Be careful! The information provided is intended to serve as a reference to assist in the selection of products sold by MARS. It is the responsibility of users to validate any cross reference information provided to determine suitability for the intended application. The company is using the competitor's brand names for reference only, and without license or permissions of those companies.
