Home  >  Comfort-Aire  >  Residential A/C & Heat Pumps  >  Air Conditioners  >  LE Series  >  CMA 14 Horizontal  > AC CONDENSER

AC CONDENSER

SIDE DISCHARGE 14.5 SEER
Coil Type Fin & Tube SEER (Min.) 14.5 Capacity (Tons) 1 Refrigerant R-410A Voltage 115V-1-60 Compressor Rotary No. of Stages 1 Max. Amps 15 Width (in.) 33.3 RLA 7 Warranty Compressor 5 yr. Parts 1 yr. Circuit Breaker 15 Depth (in.) 13.25 Min. Circuit Ampacity 10 Cabinet Galvanized steel, painted finish Sound Rating (dBA) 54 Connection Size (in.) 1/4 - 1/2 Serviceability Compressor and Component Access through Side Panel Shipping Wt (lbs) 90.4 Height (in.) 23 Matches See www.ahridirectory.org Test Listing ETL US and Canada NOTE Efficiences/capacities may vary based on airflow Certification AHRI 210/240 Factory Line-Set Charge (ft.) 25
Item #: CMA1412SF-0
AC CONDENSER

Our 14 SEER A/C condensers are compact to fit tight spaces

  • AHRI matched to CCG, MCG, coils
  • For installation in all regions

Air Conditioners

Coil Type
Fin & Tube
SEER (Min.)
14.5
Capacity (Tons)
1
Refrigerant
R-410A
Voltage
115V-1-60
Compressor
Rotary
No. of Stages
1
Max. Amps
15
Width (in.)
33.3
RLA
7
Warranty
Compressor 5 yr. Parts 1 yr.
Circuit Breaker
15
Depth (in.)
13.25
Min. Circuit Ampacity
10
Cabinet
Galvanized steel, painted finish
Sound Rating (dBA)
54
Connection Size (in.)
1/4 - 1/2
Serviceability
Compressor and Component Access through Side Panel
Shipping Wt (lbs)
90.4
Height (in.)
23
Matches
See www.ahridirectory.org
Test Listing
ETL US and Canada
NOTE
Efficiences/capacities may vary based on airflow
Certification
AHRI 210/240
Factory Line-Set Charge (ft.)
25
